Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: AYAA
  • Model Number: AY-L1506
  • Composed Type: 4S4P
  • Type: Li-Ion
  • Size: L150*W70.5*T38mm
  • Voltage: 14.8V
  • Nominal Capacity: 10.4Ah
  • Application: portable oxygen generator
  • PCM/BMS: with PCM
  • Charging voltage: 16.8±0.05V
  • Charging method: CC/CV
  • Charging current: 3.5A(0.5C)
  • Intermal resistance: ≤200mΩ

Packaging & Delivery

Packaging Details: with carton or be customize.
Delivery Detail: within 13-15 working days

4S4P 14.8V/10.4Ah Li-ion battery pack for portable oxygen generator

Product Description



4S4P 14.8V/10.4Ah Li-ion battery pack for portable oxygen generator

Model:AY-L1506

ltem

Specificatioan

Remark

Nominal capacity

10.4Ah

Samsung 18650 3.7V/2.6Ah

Nominal voltage

14.8V

3.7V/1 Cell

Charging voltage

16.8±0.05V

4.2V/1 Cell

Charging method

CC/CV

(Constant-current and-Voltage with Limited current

Standard charging time

2000mA/8hours 5000mA/3.5hours

Battery capacity÷charging current×1.5

Charging current

3.5A(0.5C)

0~+40

Maximum charging current

7A(1C)

0~+40

Continuous discharge current

3.5A(0.5C)

-20~+60

Discharge cutoff  voltage

10V

2.5V/1 Cell

Short circuit protection

Exterior short circuit

Automatic recovery

Intermal resistance

≤200mΩ

AC lmpedance 1kHz

Cycle life

≥500



Operating temperature

Standard Charge



0~+40



Standard Discharge

-20~+60



Outline dimension

L150*W70.5*T38mm

Length x wide x thickness

Pre-wired



Red=Positive,Black=Negative

Protection Circuit Module:PCM-L05S06-338

Maximal continuous charging current

7A



Maximal continuous Discharging current

7A



Over-charge detection voltage

4.325V±0.025V

Single cell

Over-charge release voltage

4.075V±0.05V

Single cell

Over-charge detection delay time

0.5S-2.0S

Single cell

Over-discharge detection voltage

2.5V±0.1V

Single cell

Over-discharge release Voltage

2.9±0.10V

Single cell

Over-discharge detection delaytime

0.5S-2.0S

Single cell

Over-current detection

25±5A



Over-current delay time

5ms-20ms
