1500W UPS off line type uninterruptible power supply/portable power supply with AC DC output for electric equipment/solar system

FOB Reference Price:Get Latest Price
US $430-600 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
AYAA
Model Number:
AY-P1500
Phase:
Single Phase
Protection:
Short Circuit
Weight:
7.8kg
Output Voltage:
AC: 220V/110V, DC: 12V/ 5V
Type:
Standby
Application:
first aid, mining, exploration, military, scientific, media, tourism,
output wave:
pure sine wave
battery pack inside:
25.9V 51.2AH
charging time:
6~8 hours
peak output power:
1300W
continuous output power:
2600W
operating temperature:
-20℃ --60℃
dimension:
34.5*24.68*17.2cm
protection function:
Over voltage, over temperation, over load, AC short circuit
Certification:
FCC, CE
Color:
Orange, Green, black
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
carbon box
Port
Shenzhen



Specification For AC-DC Portable Power Pack

Product Description

AY-P500W is off line ,dual function portable AC power station with built-in UPS.

It is with capacity 25.9V 51.2AH/1326Wh and accurate pure wave AC 220V/50hz, 110v/60hz, DC 12V 10A, 24V 10A, Double USB 5V 2A .

AY-P500W is designed with the safety lithium battery and inverter technology, which features digital display the

energy of power, emergency LED lighting, 12V cigar charger, etc.

The built-in main board with multi protected function and Intelligent battery management board ensure its safe

 for use.

NamePortable Solar Generator
Capacity25.9V/ 52800mAh   1367.52Wh
Dimensions(LWH)345*246.8*172mm
Weight12kg
Built-in BatteryHight Quality Li-ion batteries
Input RechargingDC29.4V/8A
Fully Charged TimeDC 29.4V: 7Hours
Charge modeCC/CV
OutputDC24V/10A   USB:5V/2A*2
DC Wattage(MAX)25.2-36V/20A 720W
AC Output

AC Continuous Output:1300W,

Max Output :2600WDual Pure Wave Output.

AC Voltage: Customized
according to different countries and areas.

Bulb TypeUltra Bright LED Light
Power Indicator LED Control Panel
Operation temperature range   -20℃- 60℃
Lifecycle>300 times
Safety TechnologyBuilt-in MultiSafety Protections
Package include:

1x Portable solar Genertor

1x Power Adapter

1x User manual

ColorOptional

BUILT-IN HIGH-TEMPERATURE RESISTANCE
LI-ION BATTERY

 Li-ion Batteries
Voltage25.9V
Lifecycle500-1000
Energy Density150WH/KG
Volumetric Energy(Wh/L)>320
Charging/Discharging
Effciency
>90%
Stand-by Time>3 months
Working Temperature   -20℃- 60℃
Weightlight 11~13kg
SizeSmall
Memory EffectNONE
Hazardous MaterialNone(ROHS)

BUILT-IN MULTI-SAGETY PROTECTIONS

BrandOurs
ProtectionMultiSafety Tec
Short-circuit protection reaction time grade (Lower is better)0.000000001 second
Short-circuit protection
Over-current protecion
Over-power protecion
Low-voltage protecion
Over-temperature protecion
